VRC System User Guide
26
• If Preview Panel Groups are also enabled, this bar will display the first 8
camera units for the primary group across the top and the first 8 camera units
for the preview group across the bottom of the bar.
Camera unit status colour code
The colour of the camera button indicates the current status of the camera.
Selecting Camera Units
Only camera buttons that are white or blue can be selected from the touch screen (a
green button indicates that camera is currently selected).
Depending on your user account privileges, if a camera unit is under control of
another networked control panel (button coloured Blue) you may be able to take
control of that camera using the take rudely function – see Camera control on
page 73.
If you have permission to ‘take rudely’, selecting the camera displays a confirmation
dialog (‘Device is being used by another operator, continue?’). Selecting ‘Yes’ will
transfer control of the camera to your control panel and the button turns Green.
NOTE: The camera buttons on the control panel are always the same as the
buttons currently displayed on the touch screen.
Button
Colour
Description
Green Camera currently selected and controlled by the control panel.
White Camera available for immediate selection and control.
Black Camera is offline and unavailable. see Troubleshooting on
page 85 for guidance.
Blue Camera is currently under the control of another networked
control panel. Depending on your user account privileges, you
may be able to take control of that camera unit.
Brown Pedestal is in Local/Manual mode. Switch the pedestal to Auto
mode and then bring it online by selecting Opts > Enable and
the button will turn white when the camera is enabled. see Opts
menu on page 35 for more information.
Grey Head is in Local/Manual mode. Bring the head online by
selecting Opts > Enable. See Opts menu on page 35 for more
information.
