Troubleshooting
87
At the VRC user interface:
6. Check the status colour of each camera:
• If a camera is brown - the pedestal is in Manual mode. Switch the pedes-
tal to Auto mode (see FP-145 Pedestal checklist below) and enable it with
Opts > Enable. Then, target the pedestal.
• If a camera is grey – the head is in Manual mode. Use Opts > Enable to
switch the head to Auto mode and enable it.
• If a camera is black – it is unavailable to the system. Continue with Head
and Pedestal checklists below.
Fig. 53 Camera selection and status bar
Fusion-5
FHR120-2
FP-188
FP-145-2
Fusion-7
FP-188/2
100 Head Fusion-2
Camera 9 FP-145
Fusion-6
FP-188/3
Fusion-4
FHR120
Fusion-8
Alternate
Camera Selection and Status
Pedestal in
Manual
Head in Manual Camera is
offline
Camera is online and
selected
Camera is online and
available
Camera is controlled
remotely
