Configuration
77
CCU recall preferences
If the optional CCU interface is installed for one or more cameras, the camera
functions and CCU parameters are stored for each shot. These functions and
parameters can be selectively recalled.
Fig. 42 Configuration screen – CCU Recall Preferences
Option Description
Iris Touch Iris to recall only the Iris setting with the shot. Iris
recall can be selected with or without Master pedestal
recall. If All is selected, the setting of Iris is ignored.
Master pedestal Touch Master pedestal to recall only the Master pedestal
setting with the shot.Master pedestal recall can be
selected with or without iris recall. If All is selected, the
setting of Master pedestal is ignored.
All Touch All to recall all stored camera functions and CCU
parameters with the shot. This will override the Iris and
Master Pedestal selections.
CCU Recall Preferences
Master
Pedestal
All Iris
