4
Capacitors
OK
Qty Reference Value Type Marking Part Number
1 C6 33 pF Ceramic Monolithic 33 or 330 E530144
1 C12 470 pF Ceramic Monolithic 471 E530080
3 C7, C9, C13 0.01 uF Ceramic Monolithic 103 E530019
4 C3,-5, C8 0.1 uF Ceramic Monolithic 104 E530020
2 C11, C15 0.33 uF Film 330n or 334 E530145
2 C10, C14 10 uF Electrolytic, low profile 10 uF E530045
2 C1, C16 10 uF Electrolytic 10 uF E530142
1 C2 22 uF Electrolytic 22 uF E530143
Connectors
OK Qty Reference Value Description
Part Number
1 P2 3-pin Male Header, 1x3, 0.025” square post E620053
1 P1 5-pin Male Header, 1x5, 0.025” square post E620052
1 Ctrl-J2 3-pin Female Header, 1x3 E620009
1 Ctrl-J1 5-pin Female Header, 1x5 E620051
1 J2 12-pin Female Header, 1x12 E620008
1 J1 20-pin Female Header, 2x10 E620038
1 28-pin IC Socket, 0.300” wide E620011
1 3-pin Lithium Cell Holder E980040
Transistors
OK Qty Reference
Value Marking Part Number
4 Q1, Q3-4, Q7 2N3904 2222, 3904 E580017
1 Q2 2N3906 2907, 3906 E580000
2 Q5-6 J309 J309 E580009
Diodes
OK Qty Reference Value
Marking Part Number
1 LED1 LED, Red None E570012
4 D1-4 1N5711 or SD101A 1N5711, SD101A E560004
2 D5-6 1N4148 1N4148 E560002
