Page 3

Assembly

Parts Inventory

Please check the enclosed parts with this list. Check off each item in the space provided. The number
following the check-off space is the quantity required. The part numbers referenced are not necessarily
marked on the parts. Rather, they are provided for reference when ordering replacement parts.

Parts Sorting

As you sort the parts, you may find it convenient to place them in a compartmented container for ready
access. Be careful of static electricity issues if you use an insulated container to hold the parts. Use of tape
to hold sorted parts is discouraged, as there is danger of static buildup as well as contamination of the leads
from adhesive residue.

NOTE: do not put ICs or any semiconductor component in a Styrofoam or other plastic container,

or damage from static may occur. Leave such parts in the envelope or foam provided until they

are called out in the assembly instructions.

Resistors

¼ watt, 5%, carbon film

OK Qty Reference

Value

Color

Code

Part

Number

3 R6-8

120

ohm

brown-red-brown-gold E500022

2 R11,

R13 220

ohm

red-red-brown-gold E500002

2 R17,

R18 470

ohm

yellow-violet-brown-gold

E500003

2 R15,

R16 2.2K red-red-red-gold

E500107

R1-5, R10, R19

10K

brown-black-orange-gold

E500015

1 R9

47K yellow-violet

-orange-gold

E500067

1 R14

1M brown-black-green-gold

E500024

2 watt, 5%, metal oxide

OK Qty Reference Value Marking

Part

Number

R12

43 ohm

430J or yellow-orange-black-gold

E500108
