37
Table 1 from the beginning of this section is repeated here for the factory default filter settings.
Mode Filter Center Width Notch Denoise Denoise Level
CW 1 LOW
PASS
LOW
PASS
Not avail Off 1
2 600 Hz 800 Hz Not avail Off 1
3 600 Hz 250 Hz Not avail Off 1
4 600 Hz 100 Hz Not avail Off 1
Mode Filter Low Cut High Cut Notch Denoise Denoise Level
SSB 1 LOW
PASS
LOW
PASS
Off Off 1
2 200 Hz 2.5 kHz Off Off 1
3 300 Hz 1.9 kHz Off Off 1
4 300 Hz 1.6 kHz Off Off 1
Mode Filter Center Width Notch Denoise Denoise Level
RTTY 1 LOW
PASS
LOW
PASS
Not avail Not avail Not avail
2 2.5 kHz 1000 Hz Not avail Not avail Not avail
3 2.2 kHz 300 Hz Not avail Not avail Not avail
4 1.0 kHz 200 Hz Not avail Not avail Not avail
Table 6 - Factory Default Filters
The other defaults are:
Denoiser Beta 89
Decay
71
SSB Gain 7.0 dB
CW Gain 0.0 dB
Autonotch Beta 40
Decay 07
SSB Filter Gain 0.0 dB
CW Filter Gain 0.0 dB
RTTY Filter Gain 0.0 dB
Table 7 - Other Factory Defaults
