35
Menus Summary
Mode Current Menu Next Menu
CW Main Filter
Filter Bypass
Bypass Main
SSB Main
Filter
Filter Bypass
Bypass Main
RTTY Filter
Bypass
Bypass Filter
Table 2 - Primary Menu Sequences
Menu
BAND+ BAND- RCL STORE
Main* Toggle Denoiser Toggle Autonotch** Next Menu *** Decrease Denoiser
Level
Filter* Increase Width or
Center Frequency
(Upper or lower
cut in SSB) Decrease Width or
Center Frequency
(Upper or lower cut
in SSB) Bypass Menu Toggle functions of
B A N D buttons
Bypass DSP On DSP Bypass Denoiser, or Gain*** Main Menu
Denoiser Increase Decay or
Beta
Decrease Decay or
Beta Next Menu *** Toggle functions of
BAND buttons
Autonotch Increase Decay or
Beta
Decrease Decay or
Beta Next Menu *** Toggle functions of
BAND buttons
Gain Increase Gain Decrease Gain Next Menu *** Firmware Version
* Filter is the primary menu in RTTY mode; Main in CW and SSB modes
** Only in SSB
*** Selection is mode dependent
Table 3 - Button Meaning by Menu
