196
7.2 Familiarizing the Buttons in Remote Console
Click Remote Console button on PCViewer control panel to download the remote console
application or user can install remote console application from software CD (Install Web Tool).
Name Function
(1) DirectDraw Enhance the video quality.
i
Not all graphic cards can support this function.
(2) Exit Close the Remote Console.
(3) Split Screen Mode Select from 6 different split screen type to playback the recorded
video file of all the camera, or one camera over the other or
alongside on a single screen.
i
-
If there are only 4 cameras, you won’t be able to switch to 9, 16, and 13 split
screen mode.
- To change the video quality, right-click on the screen and select between High and
Normal.
- The IWH DVR series don’t support 32-split screen display mode.
(4) Record Start/stop video recording.
(5) Emap Display the map in each area, the camera/sensor/relay location and
the warning event.
