2 advanced setting – AVer IWH5000 series User Manual
Page 102
94
5.1.1.2
Advanced Setting
To setup POS text display position, text font and color.
1.
In the System Setting dialog box, POS section, click Setting >> Advanced Setting
2.
Mark Show POS Text to allow POS data to be display on surveillance screen.
3.
If user doesn’t want POS data to be scroll up, mark Stop scroll POS Text and enter the time
to delete POS text at Erase POS text after column.
4.
Select the POS data display position on surveillance screen
– Left-Top, Left-Bottom,
Right-Top, or Right-Bottom.
5.
Mark Multiple Windows to allow more than one iPOS live data window (see also
in Preview mode) display on the preview screen mode.
6.
Mark Save Window Position that iPOS live data window position(see also
Preview mode) will be saved as next time call out position when close
7.
Select the Cameras that user wants iPOS live data to be display on Preview mode when the
iPOS Live function has been enabled. To select all cameras, mark All.
8.
To change the POS data font and color, click Font.
9.
When it is done, click Save to complete the configuration.
