101
(3) Camera
- Display
Enable/disable to show the video. Even if the video of the selected camera is hidden you can
still record the video and preview it in playback mode.
- Name
Change the camera name
- Description
Add a short comment
(4) Video Adjustment (For Analog Camera Only)
Adjust the Brightness, Contrast, Hue and Saturation of the selected camera.
(5) Input
Select the type of video camera input you are using.
- Analog Camera
The video source is coming directly from camera that is connected to the DVR.
- Remote DVR
The video source is coming from another DVR server. In the Remote DVR dialog box, enter
the server IP, port number, user ID, password and select the camera number. If you are not
sure of the server IP and port, please check the DVR server IP address in Network setting.
i The audio of remote DVR doesn’t support on remote access application such as
Remote Console.
- IP Camera
The video source is coming from IP camera. Click Setup to enter the IP Camera Settings
window.
1. In the IP Camera Settings dialog box, select to connect using Protocol or URL.
 Protocol
- Protocol: Select the bran of IP camera from drop-down list.
- Model: Please check user’s manual or vendor of IP camera.
- Video Format: select format of video.
- Channel: Select the channel that is going to be display on the surveillance
monitor.
- IP Camera Site: Enter the IP address of IP camera and Port for connection.
Please check user’s manual or vendor of IP camera how to get IP address of IP
camera. The port number of IP camera is 80 in default, unless IP camera site has
change the port number, then, use default value.
- Auto Search: User also can click Auto Search button to find all IP camera that
can be detected by DVR system on your LAN network. In Search Result window,
click the IP camera that wants to connect with it.
