AVer IWH5000 series - Manual (Page 168)

160
Name Function
(19) De-interlace To enhance the video quality. Set the de-interlace mode to #1, if you are
capturing motionless picture and #2, if it captures lots of movement.
(20) Turbo
To improve the smoothness of live video. The default is enabled( ),
but in following situation:
- The channel is IP camera and is in 1 single screen.
- The channel is remote DVR and is in 1 single screen.
- The channel is analog camera, in 1 single screen, and decoding way
is software decode
Turbo function setup is in depended for each channel. To turn off turbo
function ( ), click turbo button.
[Note] In multiple split screen mode, the turbo button is gray out.
6.1.1 To Cut and Save the Wanted Portion of the
Recorded Video
1. Use the Playback Control buttons or drag the bar on the playback progress bar and pause on
where you want to start the cut. Then, click Segment button ( ) to set the begin mark.
2. Use the Playback Control buttons or drag the bar on the playback progress bar and pause on
where you want to end the cut. Then, click Segment button ( ) to set the end mark. To
cancel segmentation or set the segment marks from the start, click Segment button ( )
again.
3. Click Export button( ) → Output Video Clip button to save the wanted clip.
4. In the Save As dialog box, locate on where you want to save the file or choose to Burn the
video segment to CD/DVD ROM (only for .*mpeg file format).
5. Select the file type and select the camera information display position when playback. The
camera information will be the information of server name that user has defined in Network
Setting.
6. If the select the file type is *.avi, user can mark Included audio to include audio in output
video segment.
7. To adjust Video Quality if needed.
8. Click Save to save the video segment.
i
Right-click function is disabling for security issue.
