AVer IWH5000 series - Manual (Page 173)

165
7.1.2 PCViewer Control Panel
Name Function
(1) Preview Mode Switch to preview mode control panel.
(2) Playback Mode Switch to playback mode control panel(see also Chapter 7.1.3 )
(3) Full screen Use the entire area of the screen to only display the video.
To return, Right click the mouse or press ESC on the keyboard.
(4) Snapshot Capture and save the screen shot in *.bmp format.
(5) Select cameras to
view
Select to the view camera from different server. In Select Camera
dialog box, Display column, click to enable/disable viewing the
camera.
Click Add Server and select the server type between DVR and IP
Cam to add.
Click Delete Server to delete the selected item.
Click Import to load the previous saved list.
Click Export to save the list.
Click Apply All to change all the camera video quality based on the
selected setting.
