BaseStation 6000 Site Controller Manual
16 | P a g e
 Timed – Enables you to set a zone to run based on its programmed times only.
 Linked – Sets a zone to use the same watering setting as a previously configured zone.
Note: You are only able to link to a zone with a lower number.
 Mirror – Sets a zone to mimic the actions of another zone.
Caution: This mode has a specialized function and is not recommended for general use.
 Disabled – Use this mode to disable the zone.
Note: If other zones are mirrored or linked to this zone they will also be disabled.
 M-Valve – Use this mode to designate this zone as the master valve. It functions as a normally closed valve that turns
on when the flow zone is activated.
 M-Val NO – Use this mode to designate this zone as a normally open master valve.
 SprTime – Use this mode to set this zone for “sprinkle time,” which is a specialized, clock-based turn on/off mode. This
mode is not recommended for general use.
ET-Time – Use this mode to configure the zone to water based on Evapotranspiration settings. In order to use this device mode,
you must have a temperature sensor attached to the Remote Base Unit. Refer to Configuring an ET Primary Zone on page 55 for
more information.
• Assign the zone to a program – Type a number in the
Prog# (2) field to associate this zone with a program.
• Connect the zone to a flow zone – The fields under
FlowZone (3) are set to default values, but you can
change them. Refer to Setting Up Flow Monitoring for
Flow Zones on page 61.
• Define the order for a “walk around” test – Type a
number in the Walk Around Order (4) field to define the
order the zone will run in during a “walk around” test.
Click the Check Walk Around (5) button to find zones
with the same walk around number.
• Reorder the list of zones – Select the Advanced (6)
option, and then type a new value in the Zone Reorder
(7) field to change the order of the zones. If you add a
new zone that you want to use as a Linked or Mirrored
zone, you will need to place the new zone above the
others in the list. Use a decimal to move a zone between two others on the list. For example, type 3.5 in the Zone Reorder
field to insert a zone between the number 3 and 4 zones. To apply and save your changes, click the Reorder button at the
bottom of the column. To cancel any unapplied changes, click the Cancel button.
