Installation Instructions
Note: Review the entire guide before beginning the installation.
1. Position the antennas in line of sight to each other to ensure
the best reception. Keep the antenna clear from metal walls
and surfaces.
2. Attach the antenna mount to a ridged 1.25” to 1.75”
diameter pole.
3. Route the antenna coaxial (coax) cable from the antenna
to the radio unit.
4. Use a lightning arrestor and a single point ground to help
protect equipment.
BL-CX-LA
High Gain Antenna
Lightning Arrestor Installation Guide
1-866-294-5847
Rev 06182013
www.baselinesystems.com
Important!
Single point grounding is the most
important aspect of a grounding scheme
and is the key to protecting your equipment
from electro magnetic pulse (EMP) surge
and lightning damage.
