W HEATHEART - SA F LEX A UGER 8. A PPENDIX
71’ - 111’ 8.1. S PECIFICATIONS
30651 R5 103
8. Appendix
8.1. SPECIFICATIONS
Important: Wheatheart Manufacturing reserves the right to change specifications without
notice.
71’ 81’ 91’ 111’
CAPACITY
Unloading Rate 8700 - 9600 Bu/Hr
DIMENSIONS
Tube Size
13”
(33.0 cm)
13”
(33.0 cm)
13”
(33.0 cm)
13”
(33.0 cm)
Height at Spout (A) Raised
49’
(14.9 m)
59’9”
(18.2 m)
61’3”
(18.7 m)
15’0”
(4.57 m)
Height at Spout Lowered
9’9”
(9.97 m)
9’3”
(9.82 m)
9’11”
(10.0 m)
42’6”
(13.0 m)
Height at Scissor (B) Raised
27’1”
(8.85 m)
29’2”
(8.89 m)
34’3”
(10.4 m)
71’6”
(21.8 m)
Height at Scissor Lowered
6’4”
(1.92 m)
6’
(1.82 m)
6’7”
(2.00 m)
54’7”
(16.6 m)
Reach at Scissor (C) Raised
26’10”
(8.20 m)
31’8”
(9.65 m)
33’6”
(10.21 m)
50’11”
(15.5 m)
Reach at Scissor Lowered
35’2”
(10.7 m)
40’9”
(12.4 m)
43’7”
(13.3 m)
42’6”
(13.0 m)
Reach at Wheel (D) Raised
26’9”
(9.15 m)
29’1”
(8.86 m)
30’1”
(9.16 m)
27’8”
(8.43 m)
Reach at Wheel Lowered
35’9”
(10.9 m)
42’0”
(12.8 m)
45’2”
(13.8 m)
33’5”
(10.2 m)
Max Transport Height
12’1”
(3.68 m)
11’8”
(3.55 m)
12’4”
(3.75 m)
n/a
Width (transport)
11’
(3.35 m)
11’8”
(3.55 m)
11’8”
(3.55 m)
15’4”
(4.67 m)
Width (with axles extended) --
15’
(4.57 m)
15’
(4.57 m)
18’4”
(5.58 m)
TIRES
Type 16” Bias Ply
Hubs 6 Bolt Automotive Type
WEIGHT
Weight
Total Weight
7015 lb
(3182.0 kg)
7865 lb
(3567.5 kg)
8690 lb
(3941.7 kg)
9380 lb
(4254.7 kg)
Axle Weight
4655 lb
(2111.5 kg)
5365 lb
(2433.5 kg)
5940 lb
(2694.3 kg)
7100 lb
(7100 kg)
Hitch Weight
2360 lb
(1070.5 kg)
2500 lb
(1134.0 kg)
2750 lb
(1247.4 kg)
2280 lb
(1034.2 kg)
PTO DRIVE
Power Requirements 100 HP 120 HP 140 HP 160 HP
PTO Speed 540 rpm
PTO Shaft 35R
OTHER
Hitch Jack 5000 lb Square Tube
