51 Beechcraft Bonanza 15e ARF Assembly Manual
□
Step 7
Attach a 9-inch servo extension lead to the ESC.
Use dental floss to secure the connection.
□
Step 8
Plug the extension lead from the ESC into the
throttle channel of the receiver.
□
Step 9
Position the nosewheel so that it is aligned with
the fuselage. Apply a small amount of threadlock
to a 2mm x 5mm machine screw. Use a #1 Phillips
screwdriver to install the servo connector to secure
the steering cable.
Radio Connections for Optional
V-Tail Installation
Additional Parts Required
7-channel receiver (if using retracts)
□
Step 1
Plug the rudder and elevator servos into their
respective channels in the receiver.
Use threadlock on all metal-to-metal fasteners
to prevent them from vibrating loose.
