48 Beechcraft Bonanza 15e ARF Assembly Manual
□
Step 2
Place the battery on the tray and secure it by
tightening the hook and loop straps onto themselves.
□
Step 3
Cut a 1-inch long piece of adhesive-backed hook
and loop tape. Use the tape to attach the main
receiver to the radio tray in front of the servos.
□
Step 4
Cut a 1/2-inch long piece of adhesive-backed hook
and loop tape. Use the tape to attach the satellite
receiver to the right-hand side of the fuselage above
the wing saddle.
Optional Cockpit Detail Kit
Installation
Parts Required
Canopy Seat backs (4)
Floor pieces (2) Rear panel
Instrument panel decal
Tools Required
Canopy glue Scissors
Paper towels
□
Step 1
Apply a bead of canopy glue around the seat back
mounts on the two cabin floor pieces.
