3 Beechcraft Bonanza 15e ARF Assembly Manual
Recommended Radio Equipment
You will need a minimum 6-channel transmitter,
receiver, and seven servos. You can also choose to
purchase a complete radio system. If you are using an
existing transmitter, just purchase the other required
equipment separately. We recommend the crystal-free,
interference-free Spektrum™ DX6i 2.4GHz DSM®
6-channel system. If using your own transmitter, we
recommend the MC35 Micro Servos from JR SPORT.
If you own the Spektrum DX6i radio, just add the
AR6200 DSM2™ 6-channel receiver and seven JR
SPORT™ MC35 Micro Servos.
Transmitter and Receiver
SPM6600 DX6i 6-Channel DSM2 without
Servos, Mode 2
Or Purchase Separately
SPMAR6200 AR6200
6-Channel Receiver Air
And
JSP20030 Micro Servo (7 required)
EFLREX12L 12-inch Lightweight Servo
Extension (2)
EFLRYH3 3-inch Y-harness, Lightweight
(3 required, 2 for V-tail version)
EFLREX6L 6-inch Lightweight Servo
Extension (2 required)
EFLREX9L 9-inch Lightweight Servo
Extension (3 required)
If Installing Both Retracts and V-Tail
SPMR7700 DX7 7-Channel Air Transmitter
Only, Mode 2
SPM6070 AR7000 DSM2 7-Channel
Receiver
The Spektrum trademark is used with
permission of Bachmann Industries, Inc.
Recommended Setup
Motor Power 15 Brushless Outrunner
Motor 950Kv (EFLM4015A)
ESC 40-Amp Pro Brushless ESC
(EFLA1040)
Battery 3200mAh 3S 11.1V 20C Li-Po
(EFLB32003S)
Propeller Electric Propeller, 11 x 8E
(APC11080E)
Optional Equipment
EFL2579 V-Tail
EFL2582 Cockpit Kit
EFLG110 10- to 15-Size Tricycle Electric
Retracts
EFLSP175 1.75-inch Aluminum Spinner
Note on Lithium Polymer Batteries
Lithium Polymer batteries are significantly more
volatile than alkaline or Ni-Cd/Ni-MH batteries used
in RC applications. All manufacturer’s instructions
and warnings must be followed closely. Mishandling
of Li-Po batteries can result in fire. Always follow
the manufacturer’s instructions when disposing of
Lithium Polymer batteries.
Required Tools and Adhesives
Tools and Equipment
Pencil Felt-tipped pen
Low-tack tape Pin vise
Sidecutters Ruler
Pliers Razor saw
Mixing sticks Mixing cups
Awl or punch Manila card stock
Paper towels Binder clips
Tapered reamer Scissors
Dental floss #64 rubber bands
Sealing iron Rubbing alcohol
10mm wrench Hobby knife with #11 blade
File #1 Phillips screwdriver
3/16-inch straight blade screwdriver
Rotary tool with cutoff wheel and drum sander
Hex wrench: 1.5mm, 2.5mm, 3/32-inch
Drill bit: 1/16, 5/64, 3/32-inch
Adhesives
Thin CA Canopy Glue
12-minute epoxy 30-minute epoxy
Threadlock
During the course of building your model
we suggest that you use a soft base for the
building surface. A large piece of bedding
foam or a thick bath towel will work well
and help protect the model from damage
during assembly.
