2. Hardware Orientation
DX-700 Rear Panel
limited to a maximum resolution of 800 x 600. In Appendix A, refer to the “
” section on page 180 for pinouts.
Warning
The DVI-I connectors on the DVI output module use
proprietary signals and pinouts.
Do not connect the output of a DVI output module to anything
other than the input of a Barco DVI LED tile. Even though the
connector is a DVI-I type connector, it is not a DVI signal, and
serious damage could result if, for example, the output was
plugged into a DVI-type monitor.
