168 DX-700 • User’s Guide • Rev 02
5. Upgrading Firmware
Firmware Upgrade Overview
cáêãï~êÉ=réÖê~ÇÉ=lîÉêîáÉï
Firmware files for the DX-700 system are loaded into the hardware at power-up. These
files are stored in the unit’s onboard flash memory. They can be upgraded using an
Ethernet connection to a PC (or laptop) that is running Director Toolset. The PC
connection is made through the Ethernet port on DX-700’s rear panel.
e~кЗп~кЙ=oÉèìáêÉãÉåíë
The following hardware items are required for upgrading DX-700:
• IBM compatible computer with an available Ethernet port.
`згймнЙк=~еЗ=açïåäç~Ç=oÉèìáêÉãÉåíë
The following list outlines computer and download requirements for upgrading the DX-700:
• Ensure that your laptop uses the Windows ® 2000 or XP operating systems.
• Ensure that the Director Toolset is installed on the PC or laptop.
• Contact Barco Technical Support for information on the location from which the
DX-700 upgrade files can be downloaded, and the proper filename. In
Appendix C, refer to the “
Contact Information ” section on page 204 for details.
réÖê~ЗбеЦ=cáêãï~êÉ
„
Use the following steps to upgrade DX-700 firmware using the Director Toolset:
1. Ensure that your PC uses the Windows
®
2000 or XP operating systems.
2. Ensure that Director Toolset is version 2.0 or later.
3. Connect the DX-700’s Ethernet port to a Switch.
4. Connect the Switch to your PC. Remember that a totally “local” network is
recommended, without IP connections to the outside world.
5. Power-up the DX-700 and use the Ethernet Menu to note its IP address.
6. Change the IP address if required. In Chapter 4, refer to the procedure outlined in
the “
Using the Ethernet Menu ” section on page 142.
7. To upgrade firmware:
a. Using Director Toolset, start the Flash Update module. On the Menu
Bar, click Modules and select Flash Update. This action opens the
Flash Update Window
.
b. For DX-700, create a package folder as follows:
\Flashfiles\DX700 package
... where is the version of the main code.
