MMD-TA-11B / MMD-TA-12B Muting Module
Instruction Manual
System Installation
67.5 mm (2.65")
86.0 mm
(3.38")
118.0 mm (4.65")
2.3 Dimensions
SSA-ML-W
+24V dc, White lens, stack-light style on
12" pole (see data sheet p/n 62097)
SSA-ML-A
+24V dc, Amber lens, stack-light style on
12" pole (see data sheet p/n 62097)
M18RGR5PNQ
+24V dc, Red, Green, Amber indication,
M18 EZ-LIGHT™ with 4-pin Euro-style QD
2.2 Accessories
Solid-State LED-Based Mute Lamp
2.1 Specifications, continued
Application Notes Mute Timing Sequences: see Appendix A
Typical Muting Applications: see Appendix B
Application Standards: see inside back cover
