4.8 GLP functions ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
148 ￭￭￭￭￭￭￭￭ 743 Rancimat
The following dialog window appears:
4 Insert GLP test set and start measurement
￭ Insert the prepared test set (see "Preparing the GLP test set",
page 145) in the channel of Block A to be checked.
￭ Connect the temperature sensor to the Pt100 connector on the
rear of the 743 Rancimat.
￭ In the dialog window GLP test for unit with serial no. x, click
on [Next >].
The test measurement is started.
As soon as the temperature defined in the method has been
reached, the following message appears:
Ext. temperature The temperature measured with the exter-
nal temperature sensor.
Measuring time The time elapsed since the start of the
temperature measurement.
