Diode LED Lutron Hi-Lume LTE - Manual (Page 2)

LTE 2-Wire Forward-Phase
ULR Listed Driver
Compatible Controls
041433
Rev. C
01/2014
Warranty:
For warranty information, please visit:
www.lutron.com/BallastDriverWarranty
Lutron, , Hi-lume, HomeWorks, GRAFIK Eye, Maestro
Wireless, Quantum, Stanza and RadioRA, are registered
trademarks and GRAFIK Systems and RadioRA 2 are
trademarks of Lutron Electronics Co. Inc.
©2013 Lutron Electronics Co., Inc.
Lutron Electronics Co., Inc.
7200 Suter Road
Coopersburg PA, 18036-1299
Compatible Controls
• Dimming Modules and Panels
• Neutral Wire Dimmers
Please consult individual component installation for
more details.
Compatible Control Lists
For assistance selecting controls, contact our LED Center of Excellence at 1.877.346.5338 or
[email protected]
Product Part Number Drivers per Control
Low-End Setting/
Load-Type Setting
HomeWorks R QS
wallbox power module
HQRJ-WPM-6D-120
1 – 10 (per output);
26 total per module
“LED LutronR A-Series 2 Wire”
GRAFIK Eye R QS
control unit
QSGR-, QSGRJ-
1 – 10 (per output);
26 total per unit
Set load-type to
“Fluorescent Module”
GRAFIK Eye R 3000
control unit
GRX-3100, GRX-3500
1 – 10 (per output);
26 total per unit
Set load-type to
“GRX-FDBI” or “GRX-TVI”
RPM-4U module (LCP,
HomeWorks R , GRAFIK
SystemsT, Quantum R )
HW-RPM-4U-120
1 – 26 (per output);
26 total per module
“LED LutronR A-Series 2 Wire”
LP-RPM-4U-120 Set load-type to “2-1”
RPM-4A module (LCP,
HomeWorks R , GRAFIK
SystemsT, Quantum R )
HW-RPM-4A-120
1 – 13 (per output);
26 total per module
“LED LutronR A-Series 2 Wire”
LP-RPM-4A-120 Set load-type to “2-1”
GP dimming panels Various 1 – 26 Set load-type to “2-1”
Note: For information about Legacy Product use in existing control application, contact [email protected]
Lutron R Neutral-Wire Dimmers
Product Part Number Low-End Setting/
Load-Type Setting
Drivers per Control
A:
Not
Ganged
B:
End-of-
Gang
C:
Middle-
of-Gang
Maestro WirelessR
dimmer
MRF2-6ND-120
Trim low-end per dimmer
Advanced Programming Mode
App Note 048370
7
1 – 8 1 – 8 1 – 8
RadioRAR 2
adaptive dimmer
RRD-6NA
“Hi-lumeR A-Series LTE LED
Driver 2-wire”
1 – 8 1 – 8 1 – 8
HomeWorksR QS
adaptive dimmer
HQRD-6NA “LED Lutron A-Series 2 Wire” 1 – 8 1 – 8 1 – 8
HomeWorksR QS
600 W dimmer
HQRD-6ND “LED Lutron A-Series 2 Wire” 1 – 8 1 – 8 1 – 8
StanzaR dimmer SZ-6ND
Trim low-end per dimmer
Installation Guide
7
1 – 8 1 – 8 1 – 8
RadioRAR 2
1000 W dimmer
RRD-10ND
Set Device Type: INC/MLV
neutral dimmer, trim high-end to
99%, trim low-end to 35%
1 – 13 1 – 13 1 – 13
HomeWorksR QS
1000 W dimmer
HQRD-10ND “LED Lutron A-Series 2 Wire” 1 – 13 1 – 13 1 – 13
A B B B C B
Lutron R Dimming Modules / Panels
7 To properly trim low-end, start at lowest setting and raise step by step until light level appears to increase. Step down
one setting. Your low-end is now properly trimmed for use with your driver
Need Help? www.lutron.com/hilumeled or call the Lutron LED Center of Excellence at 1.877.346.5338
LTE Troubleshooting
LED does not
illuminate
• Verify that the driver is wired correctly according to wiring
diagram.
• Verify that the LED load is wired correctly; red to positive,
black/white to negative.
• Verify that the LED load is compatible with the specified voltage
output of the driver.
• If using a constant voltage driver, verify that the LED load is for
“constant voltage” applications.
• If using a constant current driver, verify that the LED load is for
“constant current” applications.
• Verify that a GFCI or GFCI breaker has not tripped; drivers should
not be powered by a GFCI circuit.
• Lutron drivers are not for use with MR16 LED lamps.
LED exhibits a
flash or steppy
dimming on first
use
• Drivers will “learn” the LED load on first startup. This is a one-
time event for a particular driver/LED combination. Running the
load at full output for 5 seconds should complete “learning.”
LED is flashing,
flickering,
dropping out, or
has poor dimming
performance
• Verify that a compatible dimmer is being used to control the
driver.
• Verify that the dimmer low-end trim has been properly adjusted.
• If using a constant voltage driver, verify that the LED load is for
“constant voltage” applications.
• Verify that length of wires between driver and LED does not
exceed Lutron specification.
• Certain types of LED loads may be incompatible. 8
• Lutron drivers are not for use with MR16 LED lamps.
LED is
flashing slowly
(6 to 8 second
interval)
• If using a constant voltage driver, verify that your LED load does
not exceed the maximum specified power rating of the driver
(40 W).
• If using a constant voltage driver, verify that your LED load
matches the specified voltage output of the driver.
• If using a constant current driver, verify that your LED load falls
within the specified voltage rating of the driver.
• Verify that length of wire between driver and LED does not
exceed Lutron specification.
• Certain types of LED loads may be incompatible. 8
LED output
appears dim at
high-end
• Verify that the driver is operating in an environment within its
ambient temperature rating.
LED emits audible
noise at dimmed
levels
• Certain types of LED loads may be incompatible. 8
LED strip / array
has dark spots
• If using a constant current driver, check to see if dimming
parallel-wired LEDs with CCR driver; PWM is recommended for
these applications.
Not all LED strips /
fixtures illuminate
• Verify that multiple LEDs connected to a single driver are
properly wired.
8 Certain constant current loads may have additional circuitry and certain constant voltage loads may have
added capacitance. Contact the Lutron LED Center of Excellence at 1.877.346.5338 for more information
about these loads.
Driver Leads
Maximum driver-to-LED light engine wire length for
Constant Current Drivers:
Wire Gauge
Maximum Lead Length
200 mA
to 700 mA
710 mA
to 1.50 A
1.51 A
to 2.10 A
18 AWG (0.75 mm 2 ) 30 ft (9 m) 15 ft (4.5 m) 10 ft (3 m)
16 AWG (1.5 mm 2 ) 35 ft (10.5 m) 25 ft (7.5 m) 15 ft (4.5 m)
14 AWG (2.5 mm 2 ) 50 ft (15 m) 40 ft (12 m) 25 ft (7.5 m)
12 AWG (4.0 mm 2 ) 100 ft (30 m) 60 ft (18 m) 40 ft (12 m)
Maximum driver-to-LED light engine wire length for
Constant Voltage Drivers:
Wire Gauge
Maximum Lead Length
10 V-
to 20 V-
20.5 V-
to 40 V-
40.5 V-
to 60 V-
18 AWG (0.75 mm 2 ) 10 ft (3 m) 15 ft (4.5 m) 30 ft (9 m)
16 AWG (1.5 mm 2 ) 15 ft (4.5 m) 25 ft (7.5 m) 50 ft (15 m)
14 AWG (2.5 mm 2 ) 25 ft (7.5 m) 40 ft (12 m) 75 ft (22.5 m)
12 AWG (4.0 mm 2 ) 40 ft (12 m) 60 ft (18 m) 100 ft (30 m)
