Adjust your QBox configuration

Select different QBox video settings

A QBox has both composite and VGA signal outputs. Either video standard (PAL or NTSC) can be used for

the composite output. A variety of resolutions can be selected when using VGA output.

Note: You should choose one output only as the quality of the scroll output will be

degraded due to the differences in display formats if both outputs are enabled.

To alter the video output settings use the procedures outlined below. (You must attach a keyboard to the

QBox in order to access the configuration interface.)

1. Press the F8 key on the QBox keyboard to bring up the configuration menu.
76. Use the Down arrow key to select Configure QBox and then press Enter.

77. Use the arrow keys to select Display Settings.

78. Press Enter to view the configuration options for your monitor from which you can

choose the appropriate video output signal.

Video output

1. Use the Tab key to move through the list and use the Space bar to select the

appropriate setting.
