4.12. I/O Complex Equipment ‘SX7411F’
Description: T7411F Monitored Digital Input Module, 24V dc. The Monitored Digital Input Module
interfaces to 16 field input devices. The Type F module connects to field inputs that
switch the ‘hot’ side of field power ranging from 15V dc to 80V dc. The module
performs complete testing of the input module electronics. This board definition is
used in a simplex configuration.
Product Description reference: PD-T7031 Monitored Digital Input Modules
OEM PARAMETERS:
OEM parameter Valid numbers Description
TICS_CHASSIS
TICS_SLOT 1 – 10
1 – 8 (Chassis 1)
1 – 12 (Expander
Chassis) The TICS chassis & slot number where the TMR Interface
module is placed
REGENT_CHASSIS
REGENT_SLOT 1 – 16
1 – 10 The chassis & slot number within the Regent+Plus I/O
where the Module is placed.
MONITER_MASK 1 = mask fault LEDs
0 = enable fault LEDs Entered as a 16 bit word. Bit 0 will mask channel 1,bit 15
will mask channel 16. This field will mask the
implementation of the fault LEDs on the module. Input
status is not affected.
OPEN_VOLTAGE 0 – 240 Voltage at which to indicate failure at switch open. The
data is entered in the form of a decimal number in the
range 0 - 255. However 240 is the maximum the user
can enter to accommodate test ranges within the module.
ON_OFF_VOLTAGE 0 – 240 Voltage at which to indicate a transition from Low/High or
High/Low has taken place. It is again entered as a decimal
value the range 0 - 255. However, 240 is the maximum
the user can enter to accommodate test ranges within the
module.
SHORT_VOLTAGE 0 – 240 Voltage at which to indicate failure at switch close. The
data is entered in the form of a decimal number in the
range 0 - 255. However, 240 is the maximum the user
can enter to accommodate test ranges within the module.
