Trusted TM TMR Module T8160
Issue 13 May 13 PD-T8160 11
2.3. Module Pinout Connections
2.3.1. I/O Connector (PL 1)
This connector provides a number of discrete input and outputs. These provide the Trusted TM TMR
Interface with the connections for the Regent/ Regent+Plus I/O SafetyBus. PL 1 is a 96-way DIN
41612 C type connector. See Table 2 for connector pin-out details.
Rows
Pin A B C Description
1 RS_485_SEATED_AN RS_485_SEATED_
BN RS_485_SEATED_
CN Signal
2 nc Nc Nc No connection
3 nc Nc Nc No connection
4 SFTY_PD_A0 SFTY_PD_B0 SFTY_PD_C0 Signal (RS485)
5 SFTY_PDN_A0 SFTY_PDN_B0 SFTY_PDN_C0 Signal (RS485)
6 GND GND GND 0V
7 SFTY_PD_A1 SFTY_PD_B1 SFTY_PD_C1 Signal (RS485)
8 SFTY_PDN_A1 SFTY_PDN_B1 SFTY_PDN_C1 Signal (RS485)
9 GND GND GND 0V
10 SFTY_PD_A2 SFTY_PD_B2 SFTY_PD_C2 Signal (RS485)
11 SFTY_PDN_A2 SFTY_PDN_B2 SFTY_PDN_C2 Signal (RS485)
12 GND GND GND 0V
13 SFTY_PD_A3 SFTY_PD_B3 SFTY_PD_C3 Signal (RS485)
14 SFTY_PDN_A3 SFTY_PDN_B3 SFTY_PDN_C3 Signal (RS485)
15 GND GND GND 0V
16 SFTY_PD_A4 SFTY_PD_B4 SFTY_PD_C4 Signal (RS485)
17 SFTY_PDN_A4 SFTY_PDN_B4 SFTY_PDN_C4 Signal (RS485)
18 GND GND GND 0V
19 SFTY_PD_A5 SFTY_PD_B5 SFTY_PD_C5 Signal (RS485)
20 SFTY_PDN_A5 SFTY_PDN_B5 SFTY_PDN_C5 Signal (RS485)
21 GND GND GND 0V
22 SFTY_PD_A6 SFTY_PD_B6 SFTY_PD_C6 Signal (RS485)
23 SFTY_PDN_A6 SFTY_PDN_B6 SFTY_PDN_C6 Signal (RS485)
24 GND GND GND 0V
25 SFTY_PD_A7 SFTY_PD_B7 SFTY_PD_C7 Signal (RS485)
26 SFTY_PDN_A7 SFTY_PDN_B7 SFTY_PDN_C7 Signal (RS485)
27 GND GND GND 0V
28 SYNC_A SYNC_B SYNC_C Signal (RS485)
29 SYNC_AN SYNC_BN SYNC_CN Signal (RS485)
30 GND GND GND 0V
31 CLK_A CLK_B CLK_C Signal (RS485)
32 CLK_AN CLK_BN CLK_CN Signal (RS485)
Table 1 I/O Connector - Pin Out
