54 Specifications
Digital Meters
Number
LEDs
Size
Dimensions (HxW)
Scale
2
Removable black bezel with white faceplate
and black lettering
31 behind red tint filter
1/16 DIN
9.6 x 2.4 mm (3.8 x 0.95 in)
0 to 100%
0, 25, 50, 75, 100% major divisions
5% minor divisions
Relays
Number
Relay Rating
3 SPDT (Module/Transducer/Tachometer
Fault, Warning, and Trip)
250V ac @ 3 A resistive
Power
Volts
Amps
Watts
100 to 240V ac
0.28 to 0.12A max.
28 max.
Environmental
Operating Temperature
Storage Temperature
Relative Humidity
-20 to +65°C (-4 to +149°F)
-40 to +85°C (-40 to +185°F)
95% non-condensing
Physical
Dimensions, Cutout (HxWxD)
Dimensions, Faceplate (HxW)
18.42 x 13.82 x 30.45 mm (7.25 x 5.44 x
11.99 in)
22.23 x 14.36 cm (8.75 x 5.66 in)
Enclosure
North America
NEMA/CSA/UL
Europe
NEMA Type 1 panel mounting construction,
for indoor use
IP 20
XM-720 Technical Specifications
Product Feature Specification
