Configuring the XM-720 39

Downloading a
Pre-Configured
Configuration File

The XM-120/121/122 module (inside the XM-720 enclosure) samples inputs,
compares them to threshold values, and provides outputs to the relays and
front panel meters and LED indicators. It must be configured in order to
properly take measurements and to control the meters and LEDs.

The XM-720 package supplies configuration files (.120, .121, .122) that contain
predefined settings for a standard IEPE accelerometer, and other types of
powered and externally or self powered sensors. Use one of these
configuration files to help you set up your XM-720 monitor.

Files to Use With Your XM-720 Monitor

Tables 3.1 to 3.3 provide a list and description of the configuration files
included on the XM Documentation and Configuration Utility CD.

1440PK0205M0 (XM-120) Configuration Files

The XM Serial Configuration Utility uses the .120 file extension for the
XM-120 configuration files (XM-720 Cat. No. 1440PK0205M0).

Table 3.1 XM-120 Configuration Files

IMPORTANT

The configuration files provide a base from which to set up
your XM-720 monitor. The provided files are intended only
as an aid to configure the monitor. Please refer to the
manufacturer/OEM recommendations, historical data,
ISO and other industry standards to determine the correct
settings for your machine.

IMPORTANT

The configuration files for XM-120 module are located on
the XM Documentation and Configuration Utility CD in
the 1440PK0205M0 Configuration Files folder.

Predefined Parameter Values

Configuration File Name

Transducer
Type /
Measures

Sensitivity

Fault
Low

Fault
High

Signal
Detection

Alert
Thresholds

Danger
Thresholds

4-20 mA
Range

ACCEL.120

Accelerometer/
Acceleration

100 mv/g

6 V

18 V

Calculated
peak

2.5 g

3.5 g

0 - 5 g

ACCEL_to_VEL_metric.120

Accelerometer/
Velocity

100 mv/g

6 V

18 V

Calculated
peak

10 mm/s

15 mm/s

0 - 25 mm/s

ACCEL_to_VEL_english.120

100 mv/g

6 V

18 V

Calculated
peak

0.4 ips

0.6 ips

0 - 1 ips

DISP_metric.120

Displacement/
Displacement

7.87 mv/µm

-20 V

-2 V

True pk to pk

175 µm

225 µm

0 - 375 µm

DISP_english.120

200 mv/mils

-20 V

-2 V

True pk to pk

7 mils

9 mils

0 - 15 mils
