Page 53: Appendix

53
Publication GMSI10-UM001C-EN-E - June 2011
Appendix
A
Specifications
The Appendix lists the technical specifications for the XM-720 Machine
Monitor.
XM-720 Technical Specifications
Product Feature
Specification
Communications
Local Configuration
DeviceNet
Local configuration is provided through the
serial port connection of the
XM-120/121/122 module. The serial port is
accessed from the top or side of the
XM-720 enclosure.
NOTE: Required XM Serial Configuration Utility
software and serial cable are packaged with the
XM-720 Machine Monitor.
Remote system access is available through
the integral DeviceNet connection of the
XM-120/121/122. Consult the appropriate
XM Module Users Guide (included) and the
DeviceNet Cable System Planning and
Installation Manual (www.odva.org) if
implementing a network solution.
Inputs
2 Signal Conditioning Channels
Tachometer
Eddy current transducer signals
Accelerometer signals
Voltage signals from any dynamic
measurement device, such as a velocity or
pressure transducer
±25V (50V max. peak to peak)
1 to 50,000 events per revolution
Outputs
4-20mA Outputs
Buffered Outputs
Two isolated outputs
250 ohm max load
2 active buffers, one per channel
1 resistive buffer for tachometer
tethered dust cover
Indicators
4 Front Panel LEDs Module Fault
Transducer Fault
Warning
Trip
