Publication GMSI10-UM001C-EN-E - June 2011
Configuring the XM-720 41
1440PK0205M2 (XM-122) Configuration Files
The XM Serial Configuration Utility uses the .122 file extension for the
XM-122 configuration files (XM-720 Cat. No 1440PK0205M2).
Table 3.3 XM-122 Configuration Files
1
The XM-122 can only perform gSE measurements with an accelerometer. The gSE measurements are only
available for the channel if Eng. Units is set to "g." Refer to Editing the XM-720 Parameters on page 44 for
details.
Download the Configuration File to the XM-120/121/122
To use one of the provided configuration files, follow these steps.
1. Make certain the XM Serial Configuration Utility software is installed
onto the computer that will be connected directly to the
XM-120/121/122 module.
2. Insert the XM Documentation and Configuration Utility CD into the
CD-ROM drive of the computer.
IMPORTANT
The configuration files for XM-122 module are located on
the XM Documentation and Configuration Utility CD in
the 1440PK0205M2 Configuration Files folder.
Predefined Parameter Values
Configuration File Name
Transducer
Type /
Measures
Sensitivity
Eng.
Units
1
Fault
Low
Fault
High
Signal
Detection
Alert
Thresholds
Danger
Thresholds
4-20 mA
Range
ACCEL.122
Accelerometer/
Acceleration
100 mv/g
g
4 V
18 V
Calculated
Peak
2.5 g
3.5 g
0 - 5 g
ACCEL_to_VEL_metric.122
Accelerometer/
Velocity
100 mv/g
g
4 V
18 V
Calculated
Peak
10 mm/s
15 mm/s
0 - 25 mm/s
ACCEL_to_VEL_english.122
100 mv/g
g
4 V
18 V
Calculated
Peak
0.4 ips
0.6 ips
0 - 1 ips
