PMI Regulator / UDC Register Cross-Reference
C-1
A
PPENDIX
C
PMI Regulator / UDC Register
Cross-Reference
PMI Motherboard
Description
Register
Bit
Flex I/O data
0-9/12-21
Flex I/O errors
10-11/22-23
PMI-UDC communication status
80-89/1080-1089
PMI meter port output
106/1106
DRV RDY LED
AC Power Technology Fault
202/1202
11
P.M. FLT LED
DC bus overcurrent fault
202/1202
1
Instantaneous overcurrent fault
202/1202
3
Charge bus time out fault
202/1202
6
Over temperature fault
202/1202
7
EXT FLT LED
DC bus overvoltage fault
202/1202
0
Ground current fault
202/1202
2
Charge bus time out fault
202/1202
6
Over speed fault
202/1202
10
Application program control
101/1101
2
I/O FLT LED
Flex I/O communication error
203/1203
13
