5-6 PMI Regulator
Figure 5.4 – Terminal Block Connections for Analog Input Only
Figure 5.5 – DIN Rail Connections for Analog Input Only
1
2
3
ANALOG
ANALOG INPUT
ANALOG INPUT
SHIELD
1
2
3
4
5
6
(–)
(+) 1
WIRE
NUMBER
WIRE
COLOR
1 BLK
2 CLEAR
3 DRAIN (SHIELD)
ANALOG
Cable No. 612568-xxxS
(where xxx is length in inches)
WIRE
NUMBER
WIRE
COLOR
1 BLK
2 CLEAR
3 DRAIN (SHIELD)
ANALOG
Cable No. 612569-xxxS
(where xxx is length in inches)
