Installation Guidelines 5-1
C
HAPTER
5
Installation Guidelines
This section provides guidelines for wiring and cabling and for installing I/O modules
and peripherals. This section provides general guidelines only. Always refer to the
wiring diagrams supplied with your system for specific installation information.
5.1 Wiring Guidelines
The user must ensure that the installation of wiring conforms to all applicable codes.
To reduce the possibility of noise interfering with the control system, exercise care
when installing wiring from the system to external devices. For detailed
recommendations, refer to IEEE Standard 518.
5.2 PMI Regulator Motherboard Connections
Observe the guidelines described in the following sections when making connections
to the PMI Regulator’s motherboard.
!
ATTENTION:Only qualified electrical personnel familiar with the
construction and operation of this equipment and the hazards involved
should install, adjust, operate, or service this equipment. Read and
understand this manual and other applicable manuals in their entirety
before proceeding. Failure to observe this precaution could result in
severe bodily injury or loss of life.
ATTENTION: DC bus capacitors retain hazardous voltages after input
power has been disconnected. After disconnecting input power wait five
(5) minutes and check the voltage of the DC bus to ensure the DC bus
capacitors are discharged before touching any internal components.
Failure to observe this precaution could result in severe bodily injury or
loss of life.
ATTENTION:The user is responsible for conforming with all applicable
local, national, and international codes. Failure to observe this precaution
could result in damage to, or destruction of, the equipment.
ATTENTION:The circuit boards of the PMI Regulator contain
static-sensitive components. Do not touch the circuit boards or their
connectors without proper ESD handling equipment. When not installed,
circuit boards should be stored in anti-static bags. Failure to observe this
precaution could result in damage to, or destruction of, the equipment.
