Table of Contents

I

C

ONTENTS

Chapter 1

Introduction

Chapter 2

PMI Regulator Motherboard
2.1

Motherboard Mechanical Description .............................................................. 2-1
2.1.1 Fiber-Optic Ports ................................................................................... 2-1
2.1.2 Power Module Interface Connector....................................................... 2-2
2.1.3 Flex I/O Interface................................................................................... 2-2
2.1.4 Meter Ports............................................................................................ 2-2
2.1.5 Synchronous Transfer Port Connector.................................................. 2-3
2.1.6 LED Status Indicators ........................................................................... 2-3

2.2

Motherboard Electrical Description.................................................................. 2-7
2.2.1 PMI Processor Operation ...................................................................... 2-8
2.2.2 AC Power Technology Circuit ............................................................. 2-10
2.2.3 Power Module Interface Connector Signals ........................................ 2-12

2.2.3.1 Digital Grounds ..................................................................... 2-13
2.2.3.2 Gate Drivers.......................................................................... 2-13
2.2.3.3 Motor Current Feedback ....................................................... 2-13
2.2.3.4 Motor Voltage Feedback....................................................... 2-14
2.2.3.5 DC Bus Voltage Feedback.................................................... 2-14
2.2.3.6 Ground Current Feedback .................................................... 2-15
2.2.3.7 DESAT .................................................................................. 2-15
2.2.3.8 AC Line Feedback ................................................................ 2-15
2.2.3.9 DC Bus Pre-Charge .............................................................. 2-16
2.2.3.10 EE ROM Signals ................................................................... 2-16
2.2.3.11 N-Contactor........................................................................... 2-16
2.2.3.12 Power Supply ........................................................................ 2-16

2.2.4 Synchronous Transfer Port ................................................................. 2-17

Chapter 3

Resolver & Drive I/O Board
3.1

Resolver & Drive I/O Board Mechanical Description ....................................... 3-1

3.2

Resolver & Drive I/O Board Electrical Description........................................... 3-2
3.2.1 Resolver Input ....................................................................................... 3-2

3.2.1.1 Resolver Feedback Precautions ............................................. 3-5
3.2.1.2 Resolver Calibration................................................................ 3-5

3.2.2 Analog Input .......................................................................................... 3-7
3.2.3 Drive I/O ................................................................................................ 3-8

Chapter 4

Flex I/O Interface
4.1

Flex I/O Interface Mechanical Description ....................................................... 4-3

4.2

Flex I/O Interface Electrical Description .......................................................... 4-3

4.3

Flex I/O Error Detection ................................................................................... 4-4
