4-2 PMI Regulator
Shown below are two examples of illegal physical location combinations and their
module numbering:
ILLEGAL COMBINATIONS OF FLEX I/O:
The Flex I/O modules supported by the SA3100 PMI Regulator are listed in table 4.1.
Refer to the appropriate Flex I/O instruction manuals for specific information about the
Flex I/O modules used in your system.
Interface Cable Interface Cable
MOD 1 MOD 2 MOD 0 MOD 0 MOD 2
DIGITAL
I/O
ANALOG
I/O
DIGITAL
I/O
DIGITAL
I/O
ANALOG
I/O
Module 1 will not be read. Module 0 will not be read.
Table 4.1 – Supported Flex I/O Modules
Module Type
Catalogue Number Publication Number
Digital 24V DC
16 Point DC Sink Input 1794-IB16 1794-5.4
16 Point DC Source Output 1794-OB16 1794-2.3
16 Point DC Source Input 1794-IV16 1794-5.28
16 Point DC Sink Output 1794-OV16 1794-5.29
10 Input / 6 Output DC Combo 1794-IB10XOB6 1794-5.24
Digital 120V AC
8 Point AC Input 1794-IA8 1794-5.9
8 Point AC Output 1794-OA8 1794-5.10
Analog
8 Point Analog Input 1794-IE8/B 1794-5.6
4 Point Analog Output 1794-OE4/B 1794-5.5
4 Input / 2 Output Analog 1794-IE4XOE2/B 1794-5.15
Relay
8 Point Relay Output 1794-OW8 1794-5.19
