5-4 PMI Regulator
Figure 5.2 – Terminal Block Connections for Resolver and Analog Input
1
2
3
ANALOG
ANALOG INPUT
ANALOG INPUT
SHIELD
1
2
3
4
5
6
7
2
3
RESOLVER
REFERENCE OUT
REFERENCE OUT
SINE INPUT
1
2
3
4
5
6
7
8
9
10
4
5
6
7
8
SINE INPUT (–)
COSINE INPUT
COSINE INPUT
EXT. TRIGGER
EXT. TRIGGER
(–)
(–)
(–)
(–)
(+)
(+)
(+)
(+)
(+)
1
1
7
8
WIRE
NUMBER
WIRE
COLOR
1 BRN
2 WHT/BRN
3 RED
4 WHT/RED
5 ORG
6 WHT/ORG
7 YEL
8 WHT/YEL
1 BLK
2 CLEAR
3 DRAIN (SHIELD)
RESOLVER
ANALOG
Cable No. 612426-xxxS
(where xxx is length in inches)
