Appendix
B
Publication 2755-833
Factory Default Settings
Category of Parameters Parameter Default Setting
Enable Code 39 Yes (No on Pharma-Code Units)
Enable Interleaved 2-of-5 No Guard Bars: No
Enable Codabar No
Enable Code 128 No
ar Co e m olog
Code 128 FNC1 Character None
Bar Code Symbology
Enable UPC-A No Supplements: None
Enable UPC-E No Supplements: None
Expand UPC-E No
Enable EAN-8 No Supplements: None
Enable EAN-13 No Supplements: None
Code 39 No Include: No
Check Characters I 2 of 5 No Include: No Chec Characters
Codabar No Include: No
Code 39 00, 00, 00, 00, 00, 00, 00, 00
ar Co e m olog engths
Interleaved 2-of-5 00, 00, 00, 00, 00, 00, 00, 00
Bar Code Symbology Lengths
Code 128 00, 00, 00, 00, 00, 00, 00, 00
Codabar 00, 00, 00, 00, 00, 00, 00, 00
Enable Pharma–Code Yes (On Pharma-Code units only)
Quiet Zone Ratio Default
Space Tolerance 15
Pharma–Code
Bar Tolerance 15
Pharma–Code
Wide to Narrow Bar Ratio 2
Minimum Number of Bars 5
Scanner A Decode Direction Forward
Scanner B Decode Direction Forward
Code Verification List Blank
Laser Light Triggered
Decode Mode Package Detect
No-Read Timer None (0000 msec)
canner Control
Inter-Scan Timer None (0000 msec)
Scanner A Control
Capture Count 2
Symbols/Scan 1
Symbols/Package 1
Match Complete 1
Laser Light Triggered
Scanner B Control Decode Mode Coordinated 1 Scanner B Control
Trigger Timeout None (0000 msec)
