18–3 Specifications
Publication 2755-833
Output Modules
Catalog Number 2755-OB5S 2755-OA5S 2755-OM5S
Nominal Line Voltage –– 120 VAC 240 VAC
Maximum Line Voltage 60 VDC 140 VAC 280 VAC
Minimum Line Voltage 3.0 VDC 12 VAC 24 VAC
Maximum Peak Off State Voltage 60 VDC 400 V peak 600 V peak
Maximum Peak Off State Leakage 1.0 mA 2.5 mA RMS 4.5 mA RMS
Static off-state dv/dt –– 200 V/usec 200 V/usec
Maximum On-State Current 0.5 A DC 0.5 A RMS 0.5 A RMS
Minimum On-State Current 10 mA DC 50mA RMS 50mA RMS
Maximum 1 Cycle Surge –– 4 A peak 4 A peak
Maximum 1 Second Surge 1.5 A DC –– ––
Peak On-State Voltage 1.5 V DC 1.6 V peak 1.6 V peak
Input Modules
Catalog Number 2755-IB5S 2755-IA5S ➀ 2755-IM5S ➀
Maximum Input Voltage 32 VDC 140V RMS/VDC 280 V RMS/VDC
Minimum Input Voltage 3.3 VDC 90V RMS/VDC 180 V RMS/VDC
Input Resistance 1 k ohm – –
Maximum Input Current 32mA DC@ 32 VDC 10mA RMS@ 140 VRMS 8mA RMS@ 280VRMS
Drop Out Current 1.0 mA DC 2.5 mA RMS 1.5 mA RMS
Allowable Off-State Input Current 1.0 mA DC 3.0 mA RMS 2.0 mA RMS
Allowable Off-State Input Voltage 2.0 VDC 50 VRMS/VDC 120 VRMS/VDC
➀
AC or DC input module
