13–13 Configuration: AUX Terminal Data Entry
Publication 2755-833
0
5
STS= 00H
TNS
High Byte Low Byte
MSB LSB
1
3 2
8
CMD= 08H
Display Message on AUX Terminal/
Enable Aux Terminal for Keyboard Entry (901H)
Command Address = 901H 4
7 ”N” ”E”
10
9 ”E” ”T”
12
11 ” ” ”R”
14
13 ”A” ”C”
16
15 ”T” ”R”
18
17 ”N” ”O”
20
19 ”D” ” ”
22
21 ”T” ”A”
23 ”:” ”A”
6
Messages that are longer than the size of the AUX terminal display
will truncate.
When the host sends the command to the decoder, the text string
displays on the AUX terminal prompting you to enter data. The
message always displays at the beginning of the line in position 01.
ENTER CARTON DATA:
If the command is sent with a string length of zero (no message
defined), the decoder displays the Default Prompt Message. When
receiving the host or default prompt message, the keyboard is
enabled for one entry. Type the data and press [Enter].
ENTER CARTON DATA: 123456 [Enter]
After pressing [Enter], the keyboard is disabled until receiving the
next host command. To cancel the operation, press [Esc].
