2–8 Decoder Features
Publication 2755-833
Options available when ordering the NEMA Type 4 decoder are
listed inside the decoder’s cover. Note that on actual production
labels:
•
the base catalog number will appear in the first field following the
words “Cat No.”
•
the series letter will appear in the field following “Ser.”
•
the revision letter will appear in the field following “Rev.”.
CAT. NO. SER. REV.
POWER CORD
0 = NONE
3 = NEMA 4 European
BLANK = NEMA 4 U.S. USER MANUAL
U = NONE
BLANK = ENGLISH
I/O
B1 = I/O BOARD
B2 = I/O BOARD,
(1) D.C. IN. , (2) D.C. OUT
B5 = I/O BOARD,
1 CONN. & CABLE
B6 = I/O BOARD,
2 CONN. & CABLES
B7 = I/O BOARD, (2) CONN. & CABLES
(1) D.C. IN. (2) D.C. OUT
BLANK=NONE
DISPLAY MODULE
R1 = DISPLAY
BLANK = NONE
Power Cords
Power cords available when ordering the NEMA Type 4 decoder
include:
Option
Power Cord Description
Blank 120/240 VAC, three wire (US Color Code) unterminated power cord, 6 ft. (1.83 m)①
-0 No power cord (User must supply appropriate power cord)
-3 240 VAC, three wire (European Harmonized) unterminated power cord, 6 ft.
(1.83 m)②
① Supplied with decoder if alternate power cord is not specified in catalog number.
② The decoder is not UL listed/CSA approved when used with European Harmonized power cords.
To order a replacement power cord for the NEMA Type 4 decoder,
use the following replacement part numbers.
Replacement
Number Power Cord Description
77121-801-04 120/240 VAC, three wire (US Color Code) unterminated power cord
71721-801-05 240 VAC, three wire (European Harmonized) unterminated power cord①
① The decoder is not UL listed/CSA approved when used with European Harmonized power cords.
Decoder Options
(NEMA Type 4 Decoders)
