15–2 ASCII Host Commands
Publication 2755-833
Table 15.A Two–character ASCII commands (grouped by
function)
Page
Number
Command
Code
Command Function
Symbologies
15–8 CT Configure Bar Code Symbology and Supplements
15–9 SL Configure Bar Code Specific Length
15–11 CC Configure Code 39, I 2-of-5, Codabar Check Characters
15–12 CG Configure I 2-of-5 Guard Bar
15–13 CQ Configure Quiet Zone
15–14 CF Configure Code 128 FNC1 Character
15–15 CV Configure Code Verification List
15–16 CP Configure Pharma–Code
Scanner Control
15–18 SC Configure Scanner A Control
15–20 PB Configure Scanner B Control
15–21 IF Configure Scanner A Package Detect Filter and Sense
15–22 BF Configure Scanner B Package Detect Filter and Sense
15–23 BL Configure Scanner B Laser Mode
Primary Match Code Table
15–24 SW Write Scanner Source to Match Code Table
15–25 AB Auto-load Begin
15–25 AE Auto-load End
15–26 AL Auto-load
15–28 OS Set Output Normally Open/Normally Closed
15–29 OC Set Output Condition and Duration
15–31 OH Hold Output Open/Closed
15–33 MR Read Primary Match Code Table Entry (1-8)
15–34 MW Write Primary Match Code Table Entry (1-8)
15–35 CM Clear Primary Counter (1-8)
15–36 CO Clear All Primary Output Counters
Extended Match Code Table
15–25 AB Auto-load Begin
15–25 AE Auto-load End
15–26 AL Auto-load
15–36 CA Clear Extended Match Counters
15–37 SE Set Extended Match Counter
15–38 RC Read Extended Match Counter
15–39 SM Set Extended Match Data
15–41 RP Read Extended Match Data
15–43 RA Read All Extended Counters
15–45 CS Disable Extended Match Code Set
15–46 RS Read Extended Match Set Status
