Chapter 10
Creating Recipe Screens
10–3
To create a recipe screen:
1. Select Screen Builder from the Edit File - Option Selection menu.
The Screen Builder for the main menu (screen #1) is displayed.
2. Press [F8], enter the display screen #, and select Recipe
Screen type.
The Screen Builder for a recipe screen appears. You are asked whether
the operator is to be prompted before the recipe data is downloaded
(manual or automatic operation).
3. Enter [Y] or [N] and press [Return]. If you select [Y], the operator is
prompted to acknowledge the screen. The operator must press [ ] on
the DTAM Micro or [Y] on the DTAM Plus before the download occurs.
If you select [N], the download occurs automatically when the screen is
selected. The operator in most cases will not even see the screen, only the
message that data is being downloaded.
You are prompted for a register type.
Creating a
Recipe Screen
