Chapter 3
Designing DTAM Plus and
DTAM Micro Applications
3–8
The following example shows typical menus and screens of a DTAM Plus
application. The same application could be created on a DTAM Micro with
the following exceptions:
•
DTAM Micro screen is 2 lines by 20 characters. Large screens would
have to be shortened or broken down into separate screens.
•
The DTAM Micro cannot support a bar graph screen.
DTAM Plus Application Outline
Main Menu
1. Pump/Tank Levels
2. Pump Control
3. Flow/Level Status
4. Controller Status
Security
* Restricted Access *
Enter Your Security
Code: * * * * * * * *
Data Entry
East Tank: 38% Full
Setpoint is 280 CFM
Please Enter New
Setpoint: 145
Data Entry
West Tank: 72% Full
Setpoint is 170 CFM
Please Enter New
Setpoint:
Data Display
East Pump: 280 CFM
West Pump: 0 CFM
North Pump: 207 CFM
South Pump: 70 CFM
Data Display
Controller Status
Scan Time is: 7 ms
Controller is: Online
Battery Power: OK
Data Display
West Feed Pump
Main Pump is: Off
Fill Rate: 8 CFM
Tank is 72% Full
Sub Menu
1. East Pump/Tank
2. West Pump/Tank
Data Display Data Display
East Feed Pump
Main Pump is: On
Fill Rate: 280 CFM
Tank is 38% Full
Data Display
West Feed Pump
Efficiency: 83%
Run Time: 22 Hrs.
Next Serv: 978 Hrs.
Data Display
East Feed Pump
Efficiency: 77%
Run Time: 693 Hrs.
Next Serv: 307 Hrs.
Bar Graph
Tank Total Pumping
Rate is: 557 CFM
East Tank: 38% Full
West Tank: 72% Full
North Tank: 16% Full
South Tank: 5% full
Application Example
