Chapter 14
Entering DTAM Configuration Data
14–12
SLC Com Port Setup
Selecting Com Port Setup displays:
The Communications Port parameters have the following default values for
an SLC:
Baud Rate: 19200
Parity: Even
Data Bits: 8
Baud Rate
Default is 19200 baud. Baud rate options are 38400, 19200, 9600, 4800,
2400, 1200, and 300. Select a baud rate that matches your SLC.
Note: The DTAM Plus only supports baud rates 1200 through 19200 when
communicating with SLC processors over the DH-485 network.
Parity
Default is Even parity. Parity options are None, Odd, or Even.
Data Bits
Defines the word length. Default is eight bits. Data bit options are Seven or
Eight bits.
SLC Hardware Parameters
