Chapter 14
Entering DTAM Configuration Data
14–11
When using AB DH485 or AB BASIC protocols, you must specify the
operating parameters that allow the DTAM Plus or DTAM Micro to
communicate with the SLC controller. The DTAM settings must match the
settings of the SLC or DH-485 network. If you are communicating with a
PLC-5, refer to the next section PLC Hardware Parameters.
When you select SLC Hardware Parameters from the DPS Configuration -
Option Selection menu, the following is displayed:
DTAM Plus
Only
Applies to:
Hardware
Parameter
DTAM
Plus
DTAM
Micro Purpose
Com Port Setup
✓ ✓
Defines the baud rate, parity, and number of
data bits used for communication with an
SLC or DH-485 network.
SLC 500 Slot Configuration
✓ ✓
Specifies the number of inputs and outputs
in each controller slot. This allows the
DTAM to access the correct input and output
bit files.
Max Node Address ✓ ✓ Sets the maximum node address on a
DH-485 network.
SLC 500 Node Address ✓ ✓ Sets the node address of the SLC that the
DTAM is communicating with.
DTAM Node Address ✓ ✓ Sets the address of the DTAM.
Downgrade File
✓
Allows DTAM Plus files to be downgraded to
a Spectrum Controls format.
Advisor Update Rate
✓ ✓
Sets the rate at which the DTAM reads the
advisor register.
SLC Hardware Parameters
