Chapter 17
DTAM Plus
Printer Form Builder
17–5
9. Enter the decimal value for the control code (or ASCII character), refer
to the table below. For example, decimal 10 is equivalent to LF (Line
Feed). Press [Return] after the entry.
The Hex Value and ASCII symbol are displayed.
ASCII Code Description Decimal Value
Null 0
Start of Heading 1
Start Text 2
End Text 3
End of Transmission 4
Enquiry 5
Acknowledge 6
Bell 7
Backspace 8
Horizontal Tab 9
Line Feed 10
Vertical Tab 11
Form Feed 12
Carriage Return 13
Shift Out 14
Shift In 15
Data Link Escape 16
Direct Control 1 17
Direct Control 2 18
Direct Control 3 19
Direct Control 4 20
Negative Acknowledge 21
Synchronous Idle 22
End Transmission Block 23
Cancel 24
End of Medium 25
Substitute 26
Escape 27
Form Separator 28
Group Separator 29
Record Separator 30
Unit Separator 31
Space 32
10. Enter the remaining screen text or printer codes, press [F9] to save
the screen.
