Chapter 10
Creating Recipe Screens
10–2
The screen for creating recipe screens is similar for the DTAM Plus and
DTAM Micro. The default prompt for operator acknowledgement is
different due to differences in the DTAM Plus and DTAM Micro keypads.
DTAM Micro Default Prompt
Recipe Screen Builder Function Keys
Applies to:
Function
Key Designation
DTAM
Plus
DTAM
Micro Function
[F3] MAP SCREEN
✓ ✓
Accesses screen mapping functions that link
application screens in a logical sequence.
Link screens only after all of the screens
have been created. Refer to Chapter 12.
[F4] COPY SCREEN
✓ ✓
Copies an existing screen to or from the
current display window. Both the source
and destination screens must be of the
same type (Recipe screens).
[F8] CHANGE
SCREEN
✓ ✓
Selects another operator screen.
[F9] SAVE
✓ ✓
Saves the application without exiting the
Screen Builder function.
[F10] EXIT
✓ ✓
Prompts you to save the application to the
current file and exits the DPS software
Recipe
Screen Builder
