A–B
14
Chapter
14–1
Entering DTAM Configuration Data
This chapter describes how to set the configuration parameters of the DTAM
Plus or DTAM Micro.
Section Page
Configuration Parameters 14–1
Accessing Configuration Data 14–2
Update Interval 14–3
DTAM Advisor 14–4
Time Synchronization 14–6
Setting Master Security Code 14–8
Special Security Screen 14–9
Printer Port Parameters 14–10
SLC Hardware Parameters 14–11
PLC Hardware Parameters 14–16
The following configuration parameters can be set. These parameters are
downloaded with the application and override any settings that are currently
used by the DTAM Micro or DTAM Plus.
Applies to:
Parameter
DTAM
Plus
DTAM
Micro Description
Update Interval ✓ ✓ Defines the rate at which the screen display is updated.
DTAM Advisor
✓ ✓
Assign advisor register data allowing screen changes
by a controller. Advisor is also used to trigger alarm
screens.
Time
Synchronization ✓
Synchronizes PLC-5 or SLC 5/03 clocks with the DTAM
Plus clock. Time is either read or written to the
controller.
Set Master
Security Code
✓ ✓
Sets the master security code allowing an operator
access to security screens and codes.
Special Security
Screen
✓ ✓
Restricts access to the Special menu of the DTAM to
prevent unauthorized access to special controller
functions.
Printer Port
Parameters
✓ Defines printer port parameters of a DTAM Plus with
optional printer port.
Hardware
Parameters
✓ ✓ Defines the communication parameters between a
controller and the DTAM.
Chapter Objectives
Configuration Parameters
