Appendix D
Data Formats
D–4
32 Bit Unsigned Integer
32 Bit Unsigned Integer
Range = 0 to +4,294,967,295
(Next Sequential address)
16 Bit address #2 16 Bit address #1
MSB LSB
This data format displays two consecutive 16 bit register addresses as a 32
bit unsigned integer. It uses a memory register plus the next higher register
to form the 32 bit address.
Note: The range for the 32 bit unsigned integer is 0 to +4,294,967,295.
This format can’t be scaled to different engineering units.
32 Bit BCD (Binary Coded Decimal)
32 Bit BCD
Range = 0 to +99,999,999
(Next Sequential address)
16 Bit address #2 16 Bit address #1
1st Digit 8th Digit
This data format displays two consecutive 16 bit register addresses as a 32
bit BCD value. It uses a memory register plus the next higher register to
form the 32 bit address.
Note: The range for the 32 bit BCD value is 0 to +99,999,999.
This format may be scaled to different engineering units.
32 Bit HEX (Hexadecimal)
32 Bit HEX
Range = 0 to FFFF FFFF
(Next Sequential address)
16 Bit address #2 16 Bit address #1
1st Digit 8th Digit
This data format displays two consecutive 16 bit register addresses as a 32
bit Hex value. It uses a memory register plus the next higher register to form
the 32 bit address.
Note: The range for the 32 bit HEX value is 0 to FFFFFFFF. This format
can’t be scaled to different engineering units. Use this data format for
display-only (non-entry) operations.
