Chapter 2 Transportation and Handling
Cabinet Handling
Instructions When lifting the 1500 mm wide converter cabinet, the lifting instructions
specified below must be followed.
Overhead Lifting Method
1. Verify that the front/back lifting channels and the middle cosmetic
channels are all installed and that the connecting hardware is tightened to
the cabinet.
2. Verify that the four lifting clips have corresponding internal lifting clips
installed and connected. Lifting clip holes are 30 mm.
3.
Figure 2 is only for lifting demonstration purpose. The lifting parts may be
different depending on customers’ decision and availability of the lifting
hardware. Verify shipping weight and capacity of lifting equipment.
4. The angle between the slings (
Figure 2 ) and horizontal must be 45° or
more (70° is ideal).
5. The centre to centre distance of the two lifting points of the lifting angle or
beam is to be 1500 mm +/- 150 mm (60” +/- 6.0”).
WARNING: Do not pass cables or ropes through support holes. Always use
load-rated shackles or safety hooks in support holes. The legs of swing must not
exceed 45° from vertical.
